Pleated Metal Filter Cartridge
Pleated Candle Filter Element

Pleated Candle Filter Element

Pleated Candle Filter Element Technical Data

Raw Material

SS 316L,SS 304

Filter Rating

1~300 Microns

Filter Efficiency

99 %

Working Temperature

≤ 816 ℃

Outside Diameter

50 mm, 60 mm, 63.5 mm, 65 mm, 70 mm, 100 mm, 150 mm or others

Length

254 mm, 508 mm, 762 mm, 1016 mm or others

Gasket

PTFE,   Viton, Silicone, Buna-n, EPDM

Connector

1. DOE

2. 220

3. 222

4. 226

5. Thread (NPT,BSP,G,M,R)

6. Flange

7. Special customization

Pleated Candle Filter Element Features

1. Depth filtration

2. Large filter area

3. Large dirt holding capacity

4. Good permeability

5. Heat resistance

6. High corrosion resistance if 316L raw material



Application

Polyester filtration, polymer filtration, water treatment, steam filtration, oil filtration, pharmaceutical industry, chemical industry, chemical fiber industry, food industry, high temperature gas or liquid filtration
